Features:
Are you looking for a troffer light that comes equipped with an EM battery backup system? Look no further! Our troffer light is not only flicker-free and dimmable from 5-100% using 0-10V, but it also has a "dim to off" feature for added convenience.
With a CRI of over 80 and CCT tunability, you'll be able to adjust the color temperature to your liking - whether that be 3000K, 3500K, 4000K, or 5000K. Plus, with built-in PIR sensor and motion sensor options, you'll be getting much more than just a basic lighting solution.
But that's not all! Our adjustable CCT troffer light also includes a built-in emergency driver option, providing you with peace of mind in the event of a power outage. And with its super thin and standard depth design, you'll be able to enjoy a sleek and modern lighting solution that seamlessly integrates into any environment.
Technical Parameters:
| CRI |
>80 |
| Application |
Schools, Offices, Conference Room, Hospitality Etc. |
| Beam Angle |
120° |
| Lifespan |
50,000hrs |
| Warranty |
5 Years |
| Input Voltage |
100-277VAC Or 100-347VAC |
| Luminous Flux |
2000-2500-3000-3375LM |
| Color Temperature |
3000K / 3500K 4000K / 5000K |
| Power |
16W / 20W / 24W / 27W |
| Material |
White Powder Painted Steel |
Accessories
8W or 15W UL Listed Emergency Backup
- Listed for field Instllation-UL924 & CSA C22.2 NO. 141
- Input: 120-277VAC/347VAC 50/60Hz
- Output: 25-50VDC, 8W or 15w
- Battery Recharge Time: 24Hrs
- Surge Protection: 3KV
Advantages
HOW TO CHANGE THE WATTAGE & CCT IN THIS FIXTURE
| Power Adjustable Slide Switch Position |
| Size/Positon |
0 |
1 |
2 |
3 |
| 1X4 |
27W |
24W |
20W |
16W |
| 2X2 |
27W |
24W |
20W |
16W |
| 2X4 |
40W |
30W |
25W |
20W
|
Applications:
Schools, offices, conference room, hospitality etc.
