Noonlight 2x4FT CCT And Power Tunable LED Troffer Panel With DLC5.1 Listed

Brand Name : Noonlight

Model Number : N-TR-2X4FT

Certification : DLC / ETL / RoHS

Place of Origin : China

MOQ : 50

Price : Negotiation

Payment Terms : Western Union, Paypal

Supply Ability : 10000 Piece/Pieces per Month

Delivery Time : 28-30 Working days

Packaging Details : 1pc/inner box, 4pcs/CTN,

Product Name : DLC5.1 Premium LED Troffer

Input Voltage(V) : AC 120-277VAC or AC 120-347VAC

Power : 40W-34W-26W-20W Power Adjustable

Luminous Efficacy : 130 lm/W

Certificate : ETL/DLC 5.1 Preminum

DLC Category : Stairwell and Passageway Luminaires

Contact Now

Noonlight 2x4FT CCT & Power Tunable LED Troffer with DLC5.1 listed

CCT and Power Tuanable LED Troffer Light Description

  • Optional Emergency Backups can be integrated for emergency purpose lighting.

Features

  • CRI>80, CCT Tunable, 3000K, 3500K, 4000K and 5000K
  • CCT and Power Tuanable LED Troffer Light Minimize stock, 1 SKU can cover max. of 16 models.
  • An auxiliary to connect low voltage sensor/BLE or other IOT network.
  • DLC5.1 Premium LED Troffer Light 5-100% 0-10V dimmable, flicker free, Dim to off.

Specification

Model No DLC Input Voltage Wattage Lens CRI/CCT Rated Lumen @ 30K

Rated

Efficancy

@ 30K

 Viewing Angle

Rated Lifetime

Replacing

N-TR-24-40-XX-WC1

 P

120-347VAC/

120 - 277VAC 0- 10V Isolated

Dimmable

 40W

Frosted

Ra>80,

30K

35K

40K

50K

 5000LM

125LM/W

 120°

L70>

50000hrs

60W - 200W

Incandescent

N-TR-24-34-XX-WC1

 P

120-347VAC/

120 - 277VAC 0- 10V Isolated

Dimmable

 34W Frosted

Ra>80,

30K

35K

40K

50K

 4250LM

125LM/W

 120°

L70>

50000hrs

60W - 200W

Incandescent

N-TR-24-25-XX-WC1

 P

120-347VAC/

120 - 277VAC 0- 10V Isolated

Dimmable

 25W

Frosted

Ra>80,

30K

35K

40K

50K

3500LM

125LM/W

 120°

L70>

50000hrs

60W - 200W

Incandescent

N-TR-24-20-XX-WC1

 P

100-277VAC

or

100-347VAC

 20W

Frosted

Ra>80,

30K

35K

40K

50K

2500LM

125LM/W

 120°

L70>

50000hrs

60W - 200W

Incandescent

Advantages

HOW TO CHANGE THE WATTAGE & CCT IN THIS FIXTURE

Noonlight 2x4FT CCT And Power Tunable LED Troffer Panel With DLC5.1 Listed


CCT Tunable Slide Switch Position

Position/Group

CCT

Low

3000K(Optional)

Middle 1

3500K

Middle 2

4000K

High

5000K

CCT and Power Tuanable LED Troffer Light Installation

Suitable for surface mounted, suspended mounted.

INSTRUCTION FOR SURFACE MOUNTING

·1.Disconnect or turn off power before installation,see step ①.
·2.Put the new volumetric troffer fixture onto the T grid,see step②
·3.Make the electrical connection to the fixture in accordance with local electrical code.Make all necessary wiringconnections,observing proper voltage and polarity.See step@ . Make sure the power feeds are put into the fixturejunction box.
·4 Once finished with the electrical connection, bend the earthquak clips to attach to the T grid.See step④
·5.Turn on power, the fixture will illuminate. See step .

Noonlight 2x4FT CCT And Power Tunable LED Troffer Panel With DLC5.1 Listed

Lighting Service

NOONLIGHT Core Team have more than 15 years of experience in lighting industry. We are able to offer our valuable clients:

Noonlight 2x4FT CCT And Power Tunable LED Troffer Panel With DLC5.1 Listed

Certificate

Noonlight 2x4FT CCT And Power Tunable LED Troffer Panel With DLC5.1 Listed

CCT and Power Tuanable LED Troffer Light Applications

Schools, offices, conference room, hospitality etc.
