5000K LED Linear High Bay Lights IP65 Waterproof CCT Tunable

Brand Name : Noonlight

Model Number : N-HBL

Certification : DLC / ETL / RoHS

Place of Origin : China

MOQ : 300

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, Paypal

Supply Ability : 10000 Piece/Pieces per Month

Delivery Time : 30+ working days

Packaging Details : 1pc/inner box, 10pcs/CTN, Packing Dimension: L655xW270xH312 mm

Product Name : 1FT x 2FT Adjustable Lumen With 3000K 3500K 4000K 5000K Color Switchable 90min UL 8W Emergency Backup Inclu

Power : 50W-55W-60W-65W Adjustable

CCT : 30K/35K/40K/50K CCT Tunable

CRI : Ra>80

Waterproof : IP-65

Warranty(Year) : 5 years warrantly

Contact Now

1FT x 2FT Adjustable Lumen With 3000K 3500K 4000K 5000K Color Switchable 90min UL 8W Emergency Backup Inclu

  • Noonlight Linear Highbay Led fixture is the perfect solution for a wide variety of applications and mounting heights. Its multiple lumen packages make it an ideal choice as a one for one replacement of conventional fluorescent and metal halide high bay systems.​​
  • Available in 1x2’ wide and 1x4’ sizes, this product has a 0-10V Dimming Driver Standard (10% – 100%) and operating temperature of -40°C to +40°C (-40°F to +104°F), 30°C (86°F).

​

5000K LED Linear High Bay Lights IP65 Waterproof CCT Tunable

​

  • 120-277Vac Linear highbay One and Only Cutting Edge Class 2 Driver Techonology,
  • 1 Driver only for All of Power Up to 320W with Class 2 Certificated(100-347VAC only)
  • 4 Step Power Adujustable, and 3 CCT Tunable(Optional), minimize stock, 1 SKU can cover max. of 12 models.
  • Front Access Door for Easy Maintenance
  • Plugable PIR Sensor and Motion Sensor, Zhaga PIR & Motion Sensor
  • Built-in Emergency Driver Option

5000K LED Linear High Bay Lights IP65 Waterproof CCT Tunable

5000K LED Linear High Bay Lights IP65 Waterproof CCT Tunable

SERIES DIMENSIONS
N-HBL-12 L24.79 x W16.1 x H1.77”
N-HBL-14 L46.44 x W16.1 xH1.77”

5000K LED Linear High Bay Lights IP65 Waterproof CCT Tunable

Model No DLC Input Voltage Wattage Lens CCT Rated Lumen @ 50K

Rated

Efficancy

@ 50K

 Viewing Angle Replacing
N-HBL-12-30W-8XX-F-CTPA-[Blank,HV]-SN

Pending

100-277VAC

or

100-347VAC



 30

Frosted/

Clear

40/45/50K Tunable

or

4000K,

5000K



 4950 165 120°

100W MH,

4-lamp T8 NBF
N-HBL-12-35W-8XX-F-CTPA-[Blank,HV]-SN 35 5775
N-HBL-12-40W-8XX-F-CTPA-[Blank,HV]-SN 40 6600
N-HBL-12-50W-8XX-F-CTPA-[Blank,HV]-SN 50 8250
N-HBL-12-50W-8XX-F-CTPA-[Blank,HV]-SN

Pending

100-277VAC

or

100-347VAC




 50

Frosted/

Clear

40/45/50K Tunable

or

4000K,

5000K




 8250 165 120°

175W MH,

4-lamp T8 HBF,

2-lamp T5HO
N-HBL-12-55W-8XX-F-CTPA-[Blank,HV]-SN 55 9075
N-HBL-12-60W-8XX-F-CTPA-[Blank,HV]-SN 60 9900

200W MH,

6-lamp T8 NBF
N-HBL-12-65W-8XX-F-CTPA-[Blank,HV]-SN 65 10725
N-HBL-12-60W-8XX-F-CTPA-[Blank,HV]-SN

Pending

100-277VAC

or

100-347VAC




 60

Frosted/

Clear

40/45/50K Tunable

or

4000K,

5000K




 9900 165 120°

250W MH,

6-lamp T8 HBF, 4-lamp T5HO
N-HBL-12-70W-8XX-F-CTPA-[Blank,HV]-SN 70 11550
N-HBL-12-75W-8XX-F-CTPA-[Blank,HV]-SN 75 12375

400W MH,

6-lamp T5HO
N-HBL-12-85W-8XX-F-CTPA-[Blank,HV]-SN 85 14025
N-HBL-12-95W-8XX-F-CTPA-[Blank,HV]-SN

Pending

100-277VAC

or

100-347VAC

or

347-480VAC




 95

Frosted/

Clear

40/45/50K Tunable

or

4000K,

5000K




 15675 165 120°

400W MH,

6-lamp T5HO
N-HBL-12-105W-8XX-F-CTPA-[Blank,HV]-SN 105 17325
N-HBL-12-115W-8XX-F-CTPA-[Blank,HV]-SN 115 18975

575W MH,

10-lamp T8 HBF
N-HBL-12-125W-8XX-F-CTPA-[Blank,HV]-SN 125 20625

750W MH,

8-lamp T5HO
N-HBL-12-130W-8XX-F-CTPA-[Blank,HV]-SN Pending

100-277VAC

or

100-347VAC

or

347-480VAC


 130

Frosted/

Clear

40/45/50K Tunable

or

4000K,

5000K

 21450 165 120°

875W MH,

10-lamp T5HO
N-HBL-12-140W-8XX-F-CTPA-[Blank,HV]-SN 140 23100
N-HBL-12-155W-8XX-F-CTPA-[Blank,HV]-SN 155 25575

1000WMH,

12-lamp T5HO
N-HBL-12-170W-8XX-F-CTPA-[Blank,HV]-SN 170 28050

5000K LED Linear High Bay Lights IP65 Waterproof CCT Tunable

5000K LED Linear High Bay Lights IP65 Waterproof CCT Tunable

15W or 30W UL Listed Emergency Backup

  • Listed for field Instllation-UL924 & CSA C22.2 NO. 141
  • Input: 120-277VAC/347VAC 50/60Hz
  • Output: 25-50VDC, 15 or 30W
  • Illumination Time: 90min
  • Battery Type:Li-ion
  • Battery Recharge Time: 24Hrs
  • Surge Protection: 3KV
  • Protection:
  • Input over-current Protection (Fuse)
  • Output over-voltage Protection
  • Output Low Voltage Protection
  • Output Short Circuit Protection
  • Working Temp.: 10℃ to 50℃

5000K LED Linear High Bay Lights IP65 Waterproof CCT Tunable

Power Tunable Linear High Bay HOW TO CHANGE THE WATTAGE & CCT IN THIS FIXTURE

5000K LED Linear High Bay Lights IP65 Waterproof CCT Tunable5000K LED Linear High Bay Lights IP65 Waterproof CCT Tunable

Power Adjustable Slide Switch Position
Size/Positon 0 1 2 3
1X2 30W 35W 40W 50W
1X2 50W 55W 60W 65W
1X2 60W 70W 75W 85W
1X2 95 105 115 125
1X2 130 140 155 170

CCT Tunable Slide Switch Position
Position/Group CCT
Low 4000K
Middle 4500K
High 5000K

5000K LED Linear High Bay Lights IP65 Waterproof CCT Tunable

Noonlight offers One stop supply chain service to our clients, all of the processes are made in house, such as lasering, punching, bending, welding, painting, smt and assemblies.

5000K LED Linear High Bay Lights IP65 Waterproof CCT Tunable

5000K LED Linear High Bay Lights IP65 Waterproof CCT Tunable

Schools, offices, conference room, hospitality etc.

5000K LED Linear High Bay Lights IP65 Waterproof CCT Tunable
