PC Lens 2x2 Troffer LED Retrofit Kit Gloss White Painting 347VAC

Product Categories
Zhongshan NoonLighting Co., Ltd.
Contact Now

PC Lens 2x2 Troffer LED Retrofit Kit Gloss White Painting 347VAC

Brand Name : Noonlight

Model Number : N-TR-SLK-2X2FT

Certification : DLC / ETL / RoHS

Place of Origin : China

MOQ : 200

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, Paypal

Supply Ability : 10000 Piece/Pieces per Month

Delivery Time : 30+ working days

Packaging Details : 1pc/inner box, 4pcs/CTN,

Product Name : 2x2 Troffer LED Retrofit Kit

Input Voltage(V) : AC 120-277VAC or AC 120-347VAC

Housing : 24 Gauge Steel, Gloss White Painting, PC Lens

Light Source : 2835 SMD, CRI>80

Installation : Surface Mounted, Suspension Mounted

DLC Category : Direct Linear Ambient Luminaires & Stairwell and Passageway Luminaires

Contact Now

2x2 Troffer LED Retrofit Kit

Description

  • Noonlight LED Troffer Retrofit Kits are the ideal solution to update outdated fluorescent troffers into energy-efficient, contemporary LED systems. Each LED retrofit kit includes everything needed for a seamless installation without modifying the existing fixture mounting.
  • Super sleek fixture allows the installers no need to remove the fluorescent fixture mounting from the ceiling.

Features

  • Flick Free Troffer LED Retrofit UP TO 130LM/W
  • CRI>80, CCT Tunable, 3000K, 3500K, 4000K and 5000K
  • Minimize stock, 1 SKU can cover max. of 16 models.
  • 2 Depth Design: Super Thin & Standard
  • Troffer Retrofit With Motion Sensor 5-100% 0-10V dimmable, flicker free, Dim to off.
  • Built-in Emergency Driver Option.
  • L70>50,000hrs, 5 year warranty.

CCT and Power Tuanable LED Troffer Light Description

PC Lens 2x2 Troffer LED Retrofit Kit Gloss White Painting 347VAC

Specification

DLC 5.1 Premium
N-TR-22-27 27W 24W 20W 16W
30K 35K 40K 50K
Rated Lumen
@ 30K		 3375LM 3000LM 2500LM 2000LM
Rated Efficancy 125LM/W Lens Frosted
Input Voltage 120-347VAC/120 - 277VAC 0- 10V Isolated Dimmable
Warranty 5 Years Installation Surface Mounted, Suspension Mounted

Accessories

PC Lens 2x2 Troffer LED Retrofit Kit Gloss White Painting 347VAC

PC Lens 2x2 Troffer LED Retrofit Kit Gloss White Painting 347VAC

Bi-level 12V PIR Sensor/PIR Sensor with Daylight Harvesting

Specification

  • Input: 12-24VDC, >8ma
  • 0-10V DC output signal
  • Memeory function with one bottun commissiong.
  • IR Remote controller commission.
  • Detecton Range: Max. 6m in diameter.
  • Mounting Height: 3-4m.
  • Optional Daylight Harvesting

Troffer Retrofit With EM Battery Backup

PC Lens 2x2 Troffer LED Retrofit Kit Gloss White Painting 347VAC

8W or 15W UL Listed Emergency Backup

  • Listed for field Instllation-UL924 & CSA C22.2 NO. 141
  • Input: 120-277VAC/347VAC 50/60Hz
  • Output: 25-50VDC, 8W or 15w
  • Illumination Time: 90min
  • Battery Type:Li-ion/Ni-MH
  • Battery Recharge Time: 24Hrs
  • Surge Protection: 3KV

Advantages

HOW TO CHANGE THE WATTAGE & CCT IN THIS FIXTURE

PC Lens 2x2 Troffer LED Retrofit Kit Gloss White Painting 347VAC

Power Adjustable Slide Switch Position

Size/Positon

0

1

2

3

1X4

27W

24W

20W

16W

2X2

27W

24W

20W

16W

2X4

40W

30W

25W

20W

Applications

Schools, offices, conference room, hospitality etc.

PC Lens 2x2 Troffer LED Retrofit Kit Gloss White Painting 347VAC
