180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

Brand Name : Noonlight

Model Number : NL-LC4-4FT

Certification : DLC / ETL / RoHS

Place of Origin : China

MOQ : 200

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, Paypal

Supply Ability : 10000 Piece/Pieces per Month

Delivery Time : 30+ working days

Packaging Details : 1pc/inner box, 4pcs/CTN,

Product Name : 4” Wide 4FT 40W 25W 18W 12W Power Adjustable 1600-5200lm LED Corner Stairwell Light 3000K 3500K 4000K 5000K Adjustable

Input Voltage(V) : AC 120-277VAC or AC 120-347VAC

Power : 40W-25W-18W-12W Power Adjustable

CCT : 30K/35K/40K/50K Tunable

Luminous Efficacy : 125 lm/W

Housing : 24 Gauge Steel, Gloss White Painting, PC Lens

Light Source : 2835 SMD, CRI>80

Installation : Surface Mounted, Suspension Mounted

Warranty : 5 years

Certificate : ETL/DLC 5.1 Preminum

DLC Category : Direct Linear Ambient Luminaires & Stairwell and Passageway Luminaires

Contact Now

4” Wide 4FT 40W 25W 18W 12W Power Adjustable 1600-5200lm LED Corner Stairwell Light 3000K 3500K 4000K 5000K Adjustable

180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

  • 4” LED Corner LED Stairwell fixture is a fan style linear led fixture, available with 2ft, 4ft and 8ft long.
  • Integral with new trend of field-adjustable functions provide our customers greater flexibility on wattages and color temperatures.

  • Optional Occupancy Sensor & Built-in Emergency Backup

  • Ideal for stairwell, passageway and general lighting etc.

180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

  • UP TO 135LM/W
  • CLASS P Programmable LED Driver, 4 Step Power Adujustable,
  • CRI>80, CCT Tunable, 3000K, 3500K, 4000K and 5000K
  • Minimize stock, 1 SKU can cover max. of 16 models.
  • An auxiliary to connect low voltage sensor/BLE or other IOT network.
  • Various Lens Option: Clear, Frosted,
  • 5-100% 0-10V dimmable, flicker free, Dim to off.
  • Built-in PIR Sensor and Motion Sensor Options.
  • Built-in Emergency Driver Option.
  • L70>50,000hrs, 5 year warranty.

180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

Model No DLC Input Voltage Wattage Lens CRI/CCT Rated Lumen @ 50K

Rated

Efficancy

@ 50K

 Viewing Angle Replacing
N-LC4-4FT-40W-1XX-
[Blank, S1, S2]-C-FL-
CT-FA-Z		 YES

100-277VAC

or

100-347VAC

 40

Frosted/

Clear

Ra>80,

30K

35K

40K

50K

 5130 126 180°

2 X T5HO 4FT 54W

3 X T8 4FT

32W
N-LC4-4FT-25W-1XX-
[Blank, S1, S2]-C-FL-
CT-FA-Z		 YES

100-277VAC

or

100-347VAC

 25

Frosted/

Clear

Ra>80,

30K

35K

40K

50K

 3300 130 180°

2 X T5HO 4FT 54W

3 X T8 4FT

32W
N-LC4-4FT-18W-1XX-
[Blank, S1, S2]-C-FL-
CT-FA-Z		 YES

100-277VAC

or

100-347VAC

 18

Frosted/

Clear

Ra>80,

30K

35K

40K

50K

 2340 132 180°

2 X T5HO 4FT 54W

3 X T8 4FT

32W
N-LC4-4FT-12W-1XX-
[Blank, S1, S2]-C-FL-
CT-FA-Z		 YES

100-277VAC

or

100-347VAC

 12

Frosted/

Clear

Ra>80,

30K

35K

40K

50K

 1650 128 180°

1 X T8 4FT

32W

180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

HOW TO CHANGE THE WATTAGE IN THIS FIXTURE

180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

Power Adjustable Slide Switch Position

Size/Positon

W1

W2

W3

W4

2FT

30W

20W

14W

10W

4FT

40W

25W

18W

12W

CCT Tunable Slide Switch Position

Position/Group

CCT

CCT1

3000K

CCT2

3500K

CCT3

4000K

CCT4

5000K

180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

Noonlight offers One stop supply chain service to our clients, all of the processes are made in house, such as lasering, punching, bending, welding, painting, smt and assemblies.

180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification
180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification
180 Degree 1600-5200lm LED Stairwell Lights With RoHS Certification

Stairwell Lighting, Passageway Lighting, Corridor Lighting, Shop Lighting, Strip Lighting, Low Bay Lighting, Warehouse Lighting
